| Weight |
2.1 kg |
| Dimensions |
89 × 333 × 315 mm |
| AI Search (Face Recognition) |
Up to 8 target face images at the same time
|
| AI Functions |
Face Recognition / Perimeter Protection / Smart Motion Detection (SMD+)
|
| AI Search (Perimeter Protection) |
Search by target classification (Human, Vehicle)
|
| AI Search (SMD+) |
Search by target classification (Human, Vehicle)
|
| Alarm Input / Output |
N/A
|
| Audio In/Out |
1 input / 1 output (RCA)
|
| Auxiliary Inputs |
1 x RS485 port (for PTZ control)
|
| Backup Modes |
USB Device / Network
|
| Bit Rate |
32Kbps ~ 6144Kbps Per Channel
|
| Coax Input Support |
8 channels up to 8.0MP/7fps (HDCVI), 960H/25fps (analogue)
|
| Database Application |
Each database can be applied to video channels independently
|
| Database Management |
Up to 10 face databases with 20,000 face images in total. Name, gender, birthday, nationality, address, ID information can be added to each face picture.
|
| Dimensions |
260mm x 238mm x 48mm (1U)
|
| Display Resolution |
HDMI: 3840 x 2160 to 1280 x 720 ; VGA: 1920 x 1080 to 1280 x 720
|
| Display Split |
1/4/8/9 (16 with IP extension mode enabled)
|
| Ethernet |
1x RJ-45 port (1000MB)
|
| Frame Rate (Main) |
8.0MP (1~7fps), 6.0MP (1fps~10fps), 4.0MP (1~15fps), 1080p and lower (1~25fps)
|
| Frame Rate (Sub) |
960H (1 ~15fps)
|
| Frame Rate (Third) |
N/A
|
| Internal HDD |
1 x SATA port, up to 16TB, max. 16TB HDD capacity
|
| IP Input Max. Bandwidth |
128Mbps
|
| IP Input Max. Resolution |
8.0MP
|
| IP Input Support |
8 channels
|
| Main Processor |
Embedded Processor
|
| Max. User Access |
128 users
|
| Maximum Resolution |
Configurable from 8.0MP (3840 x 2160) to CIF (352 x 288)
|
| Network Functions |
HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P
|
| Object Classification (Perimeter Protection) |
Human / vehicle secondary recognition for tripwire and intrusion
|
| Operating Environment |
-10°C ~ 55°C / 10% ~ 90% RH
|
| Operating System |
Embedded Linux
|
| OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording
|
| Performance (Face Recognition) |
Max. 12 pictures per second, 2 channel video stream only supports analog cameras (Performance varies depending on camera and resolution)
|
| Performance (Perimeter Protection) |
2 channels, 10 IVS rules for each channel (advanced) ; 8 channels, 10 IVS for each channel (general)
|
| Performance (SMD+) |
8 Channels
|
| Playback Sync |
1/4/9
|
| Power Consumption |
<10W
|
| Power Supply |
12VDC / 2A
|
| Rackmount Units |
N/A
|
| Rackmountable |
No
|
| Record Interval |
1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
|
| Record Modes |
Manual / Schedule (Regular, Continuous), Motion Detection, Video Loss, Alarm, Stop
|
