| Weight |
6.94 kg |
| Dimensions |
500 × 530 × 210 mm |
| Alarm Interface |
16 channels input, 6 channels output
|
| Alarm Actions |
Begin record, take snapshot, camera external alarm output, access controller, audio, buzzer, NVR log, camera preset, email
|
| Alarm Types |
General (motion, video loss, scene change, etc.), Anomalies (camera disconnect, disk full, IP conflict , etc.), Intelligent (AI alerts, face, human/vehicle, etc.)
|
| ANPR (By Camera) |
8 channels
|
| ANPR Functions |
Up to 20,000 plate numbers, blocklist & allowlist
|
| App Integration |
iOS / Android
|
| Audio |
1 channel input (RCA), 1 channel output (RCA)
|
| Backup Method |
USB device / Network / eSATA
|
| Decoding Capacity (AI Disabled) |
4CH@8.0MP/25fps, 16CH@1080P/25fps
|
| Decoding Capacity (AI Enabled) |
4CH@8.0MP/25fps, 16CH@1080P/25fps
|
| Dimensions |
440mm × 411mm × 76mm
|
| Display Mode |
Multiple sources: HDMI1+VGA (Mirror), HDMI2
|
| Display Output |
2 x HDMI (up to 3840 x 2160), 1 x VGA (up to 1920 x 1080)
|
| Display Split |
1st screen – 1/4/8/9/16/25/36, 2nd screen – 1/4/8/9/16
|
| Face Detection (By Camera) |
16 channels
|
| Face Detection (By NVR) |
4 channels (up to 12 face images per second, per channel)
|
| Face Detection Functions |
Gender, Age Group, Glasses, Expressions, Face Mask, Beard
|
| Face Recognition (By Camera) |
16 channels
|
| Face Recognition (By NVR) |
4 channel (Face detection via NVR video stream analysis; Face recognition performed by NVR) 16 channels (Face detection performed via Face Capture cameras via image stream; Face recognition performed via NVR)
|
| Face Recognition Capacity |
NVR Supports up to 20 face databases and 20,000 face images
|
| HDD |
4 x SATA bays, up to 16TB per bay
|
| HDD Capacity |
4
|
| Human/Vehicle Detection (By Camera) |
IVS: 16 channels, SMD: 16 channels
|
| Human/Vehicle Detection (By NVR) |
IVS: 12 channels (10 rules per channel), SMD: 12 channels
|
| Human/Vehicle Detection Functions |
AI Tripwire & Intrusion (IVS), AI Motion Detection (SMD)
|
| Interoperability |
ONVIF 2.4, SDK, CGI
|
| Network Bandwidth (AI Disabled) |
320Mbps (incoming/recording/outgoing)
|
| Network Bandwidth (AI Enabled) |
160Mbps (incoming/recording/outgoing)
|
| Network Functions |
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search, Easy4ip
|
| Network Input |
1 x 1000Mbps Ethernet uplink, 16 x PoE 100Mbps (802.3af/at), ports 1-8 supports ePoE
|
| NVR Operated AI |
Face Detection, Face Recognition, AI Human/Vehicle Detection, Video Metadata
|
| Operating Environment |
-10°C ~ +55°C / 0 ~ 90%RH / 86 ~ 106kpa
|
| Playback Channels |
Up to 16 channels
|
| Playback Modes |
General Recording, Motion Detection, Intelligent Events, Alarm Triggers, POS
|
| PoE |
Yes
|
| Power Consumption |
<21.1W (without HDD) / PoE: 25.5W per port, 150W total
|
| Power Supply |
Single, AC100V~240V, 50~60 Hz
|
| Processor & Operation |
Industrial-grade processor, Embedded Linux OS, Web Interface / Local GUI
|
| Rackmount Units |
1.5U
|
| Rackmountable |
Yes
|
| Recording Resolution |
Configurable from: 24.0MP (6016 x 4016) to D1 (704 x 480)
|
