| Weight |
8.59 kg |
| Dimensions |
499 × 571 × 211 mm |
| Alarm Interface |
16 channels input, 8 channels output
|
| Alarm Actions |
Begin record, take snapshot, camera external alarm output, audio, buzzer, NVR log, camera preset, email
|
| Alarm Types |
General (motion, video loss, scene change, etc.), Anomalies (camera disconnect, disk full, IP conflict , etc.), Intelligent (AI alerts, face, human/vehicle, etc.)
|
| ANPR (By Camera) |
32 channels
|
| ANPR Functions |
Up to 20,000 plate numbers, blocklist & allowlist
|
| App Integration |
iOS / Android
|
| Audio |
1 channel input (RCA), 2 channel output (RCA)
|
| Backup Method |
Portable hard drive / Burner / USB device / Network / eSATA
|
| Decoding Capacity (AI Disabled) |
8CH@8.0MP/25fps, 128CH@D1/25fps
|
| Decoding Capacity (AI Enabled) |
8CH@8.0MP/25fps, 128CH@D1/25fps
|
| Dimensions |
440mm × 460mm × 95mm
|
| Display Mode |
Single Source (Mirrored): HDMI1@4K, HDMI2@4K, HDMI3@8K, HDMI4@1080p, VGA1@1080p, VGA2@1080p Multiple Sources (Up to 4 sources): HDMI1@4K + VGA1@1080p (mirror), HDMI2@4K + VGA2@1080p (mirror), HDMI3@4K, HDMI4@1080p
|
| Display Output |
4 x HDMI (up to 3840 x 2160), 2 x VGA (up to 1920 x 1080)
|
| Display Split |
1st Screen: 1/4/8/9/16/25/36/64, 2nd Screen: 1/4/8/9/16/25/36
|
| Face Detection (By Camera) |
64 channels
|
| Face Detection (By NVR) |
4 channels (up to 12 face images per second, per channel)
|
| Face Detection Functions |
Gender, Age Group, Glasses, Expressions, Face Mask, Beard
|
| Face Recognition (By Camera) |
64 channels
|
| Face Recognition (By NVR) |
4 channels (Face detection via NVR video stream analysis; Face recognition performed by NVR) 20 channels (Face detection performed via Face Capture cameras via image stream; Face recognition performed via NVR)
|
| Face Recognition Capacity |
NVR Supports up to 40 face databases and 300,000 face images
|
| HDD |
8 x SATA bays up to 16TB per bay, RAID 0/1/5/6/10, Hot swapping
|
| HDD Capacity |
8
|
| Human/Vehicle Detection (By Camera) |
IVS: 64 channels, SMD: 64 channels
|
| Human/Vehicle Detection (By NVR) |
IVS: 24 channels (10 rules per channel), SMD: 32 channels
|
| Human/Vehicle Detection Functions |
AI Tripwire & Intrusion (IVS), AI Motion Detection (SMD)
|
| Interoperability |
ONVIF (Profile T; Profile S; Profile G); CGI; SDK. Supports RTSP, Sony, Samsung, Axis, Pelco, Arecont, Canon. Chrome, IE9 and later, Firefox support.
|
| Network Bandwidth (AI Disabled) |
1024Mbps (incoming/recording), 800Mbps (outgoing)
|
| Network Bandwidth (AI Enabled) |
512Mbps (incoming/recording), 400Mbps outgoing
|
| Network Functions |
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search, Easy4ip
|
| Network Input |
2 x 2500Mbps Ethernet
|
| NVR Operated AI |
Face Detection, Face Recognition, AI Human/Vehicle Detection, Video Metadata
|
| Operating Environment |
-10°C ~ +55°C / 10 ~ 93%RH
|
| Playback Channels |
Up to 16 channels
|
| Playback Modes |
General Recording, Motion Detection, Intelligent Events, Alarm Triggers
|
| PoE |
No
|
| Power Consumption |
? 18W (without HDD)
|
| Power Supply |
100240 VAC / 50-60 Hz
|
| Processor & Operation |
Industrial-grade processor, Embedded Linux OS, Web Interface / Local GUI
|
| Rackmount Units |
2U
|
| Rackmountable |
Yes
|
| Recording Resolution |
Configurable from 32.0MP (6528 x 4896) to D1 (704 x 576)
|
