The sensor analyses two sequential signals of different frequencies allowing detection of both shock signal and glass breakage preventing false alarms. The detector can be mounted on a wall providing up to 15m movement and 10m glass break coverage, allowing you to protect several windows at once.
Product features:
ƒ?› Quad (Four element) pyrosensor
ƒ?› Two independent relay outputs for GLASS/SHOCK and PIR alarm signals
ƒ?› Adjustable PIR / GLASS / SHOCK sensitivity
ƒ?› Automatic temperature compensation
ƒ?› Height installation: 1.8 ~ 2.4m
ƒ?› Pet immunity up to 25Kg (active below 1m)
ƒ?› PIR Range: 15m
ƒ?› Glass?ÿBreak?ÿRange: 10m
ƒ?› EMI?ÿProtection: 50,000V
ƒ?› Contacts?ÿof?ÿAlarm: N.C.
ƒ?› Dimensions: 120 x 65 x 45mm
ƒ?› Input?ÿVoltage: 12V
